Mining Cable - Product Detail

Product Overview

Our mining cables are engineered specifically for the harsh and demanding environments of underground and surface mining operations. They are designed to deliver reliable power, control, and communication in conditions involving mechanical stress, moisture, chemicals, and extreme temperatures.

Key Features & Advantages

• Robust Construction: Features heavy-duty elastomer jackets (like CSP/CPE) offering superior resistance to abrasion, crushing, impact, oil, and flame.

• Enhanced Flexibility: Specially stranded conductors and flexible insulation materials allow for easier handling and installation around machinery and in confined spaces.

• Exceptional Safety: Compliant with stringent international standards for flame retardancy and low smoke emission (e.g., MSHA, IEC), ensuring safer operation in case of fire.

• Optimal Conductivity: Utilizes high-purity copper conductors with precise stranding for efficient power transmission and minimal voltage drop.

• Reliable Performance: Excellent resistance to ozone, weathering, and hydrolysis ensures long-term durability and reduces downtime.

Technical Specifications

• Compliance Standards: Manufactured in accordance with GB, IEC, and other relevant international standards (e.g., IEC 60245, IEC 60502).

• Conductor: High-grade, finely stranded bare copper or tinned copper.

• Insulation: Specialized rubber compounds (EPR, CSP) or cross-linked polyethylene (XLPE) for thermal stability and dielectric strength.

• Jacket: Heavy-duty, color-coded elastomer compound resistant to mechanical abuse, oils, and flame propagation.

• Voltage Rating: Commonly available from 300/500V up to 0.6/1kV and 1.8/3kV.

• Core Configurations: Ranging from 3 cores + Earth to multi-core configurations for power and control applications.

• Temperature Range: Flexible operation typically from -20°C to +90°C (dependent on specific construction).

Common Applications

• Power supply for continuous miners, shearers, shuttle cars, and longwall equipment.

• Trailing cables for excavation and haulage machinery.

• Control and monitoring circuits for mining equipment.

• Lighting systems and auxiliary power in underground mines.

• Surface mining equipment connections.

Why Choose Our Mining Cables?

1. Proven Durability: Built to withstand the toughest mining conditions, ensuring extended service life and reduced replacement costs.

2. Safety First: Our cables meet or exceed critical safety standards, prioritizing the protection of personnel and infrastructure.

3. Customizable Solutions: We offer tailored designs for specific voltage, core count, length, and performance requirements.

4. Certified Quality: Backed by ISO 9001 quality management system and relevant product certifications for assured reliability.

5. Technical Support: Our engineering team provides expert guidance for product selection and application support.

Anhui Keyuan Cable Group Co., Ltd. is committed to providing robust, safe, and high-performance cable solutions for the global mining industry. Contact us to discuss your specific project needs.
